OTL19F 19″ PCAP Touchmonitor

Name

19 Inch Closed Frame Touchmonitor

Model

OTL19F

LCD Panel Parameters

Display Technology

Active Matrix TFT-LCD with LED Backlight

Aspect Ratio

5:4

Active Area (W × H)

376.32 mm × 301.06 mm

Native Resolution

1280×1024 @60Hz

Response Time (Typ.)

5 ms

Display Colors

16.7 million

Luminance (Typ.)

250nits, with PCAP 210nits

Contrast Ratio (Typ.)

1000:1

Viewing Angle (Typ.)

Horizontal (left/right) CR≥10 85°/85°

Vertical (up/down) CR≥10 80°/80°

Touch Screen Parameters

Touch Technology

PCAP

Cover Glass Treatment

Strengthened

Cover Glass Surface Treatment

Optional: Anti-Glare

Impact Resistance Level

IK08

Active Area (W × H)

377.3 mm × 302.1 mm ± 0.3 mm

Thickness (Total)

4.4 ± 0.3 mm

Light Transmission

≥83%

Response Time

8 ms

Touch Screen Interface

USB

Touch Point

10

Overall Parameters

Case/Bezel Color

Mounting Options

VESA: 75 × 75 mm, 100 × 100 mm

Outline Dimensions（W×H×D）

433.6mm × 356.6mm × 39.8mm

Power Supply

On Screen Display (OSD)

Control (Back): Power, Auto, Up, Down, Menu

Power Consumption

MAX: 12W

Speaker

Optional

Webcam

NA

Operating Altitude

≦3000 m

Temperature Range

Operating: 0℃ to 40℃, Storage: -20℃ to 60℃

Humidity (Non Condensing)

Operating: 20% to 80%, Storage: 10% to 90%

I/O

VGA, HDMI, USB (Type B, For Touch)

Accessories

Cables: VGA×1, USB×1, 1.5m Length

Carton Box Dimensions

555mm (L) × 460mm (W) × 185mm (H), 1 unit in one carton

Weight

Net: 5.5kg

Gross: 7.2kg

MTBF

50,000 hours demonstrated

Agency Approvals

CCC, CE, FCC, UKCA

Warranty

3 years

Ordering Information

Part Name

Part Number

Description

OTL19F-RC5000-UH2A00-2.0
