OTR247 23.6″ Circle LED-edge
|
Name |
23.6 Inch Circular Touchmonitor |
|
Model |
OTR247 |
|
LCD Panel Parameters |
|
|
Display Technology |
Active Matrix TFT-LCD with LED Backlight |
|
Aspect Ratio |
1 : 1 |
|
Active Area (W x H) |
599.42mm × 599.42mm |
|
Native Resolution |
1280 × 1280 @ 60 Hz |
|
Response Time (Typ.) |
14 ms |
|
Display Colors |
16.7 M |
|
Luminance (Typ.) |
1500 nits |
|
Contrast Ratio (Typ.) |
1000 : 1 |
|
Viewing Angle (Typ.) |
Horizontal (left/right) CR≥10 89°/89° |
|
Vertical (up/down) CR≥10 89°/89° |
|
|
Touch Screen Parameters |
|
|
Touch Technology |
PCAP |
|
Cover Glass Treatment |
Strengthened |
|
Cover Glass Surface Treatment |
Optional: Anti-glare |
|
Impact Resistance Level |
IK07 |
|
Thickness (Total) |
3.5mm |
|
Light Transmission |
≥83% |
|
Response Time (Typ.) |
10 ms |
|
Touch Screen Interface |
USB |
|
Touch Point |
10 |
|
Overall Parameters |
|
|
Case/Bezel Color |
Black |
|
Mounting Options |
VESA: 200 mm × 150 mm |
|
Outline Dimensions（W×H×D） |
690.0 mm × 690.0 mm × 55.6 mm |
|
Power Supply |
Input Voltage Range: Monitor: +24 VDC ± 5%, 4 PIN plug or 6 PIN mating Molex 3901-2060 RGB LED Lights: +12VDC ± 5%, mating Molex 43025-0600 Optional LED controller (External): +12VDC ± 5%, Coaxial power jack 2.5mm pin outer diameter |
|
On-Screen Display (OSD) |
Control (Back): Power, Auto, Up, Down, Menu |
|
Power Consumption (Max.) |
100W ( Monitor without RGB LED Lights) 20W (RGB LED Lights) |
|
Operating Altitude |
≤3000 m |
|
Temperature Range |
Operating: 0℃ to 40℃, storage: -20℃ to 60℃ |
|
Humidity (Non-Condensing) |
Operating: 20% to 80%, storage: 10% to 90% |
|
I/O |
HDMI, DP, USB (Type B） |
|
Accessories |
Optional |
|
Carton Box Dimensions |
785mm (L) × 785mm (W) × 185mm (H), 1 unit in one carton |
|
Weight |
Net: 12.8 kg, Gross: 18.5 kg |
|
MTBF |
50,000 hours demonstrated |
|
LED Lights Color |
Multicolor |
|
LED Lights Location |
Circular lights bar (Front & Edge) |
|
LED controller (External) |
Optional |
|
Agency Approvals |
CE, FCC, UKCA |
|
Warranty |
3 years |
|
Ordering Information |
||
|
Model |
Part Number |
Description |
|
OTR247-RC4000-UDBT40-1.0 |
10202010550R |
23.6”, circular, 1500nits, PCAP, USB, HDMI & DP, LED lights Location front & edge |
|
OTR245-RC4000-UDBT00-1.0 |
10202010567R |
23.6”, circular, 1:1, 1500nits, PCAP, USB, HDMI & DP |
|
OMR247-R03000-0DBT40-1.0 |
10205010096R |
23.6”, circular, 1500 nits, non-touch, HDMI & DP, LEDlights Location front & edge |
|
OMR245-R03000-0DBT00-1.0 |
10205010095R |
23.6”, circular, 1:1, 1500nits, non-touch, HDMI & DP |
